1-3
1
Confirmations upon Delivery
Checks
Check the following items as soon as the Inverter is delivered.
In case of any irregularities in the above items, contact the agency from which the Inverter was purchased or
your Omron-Yaskawa Motion Control representative immediately.
Nameplate Information
The nameplate attached to the side of each Inverter showing the model number, specifications, lot number,
serial number and other information about the Inverter.
Example Nameplate
The following nameplate is an example for a standard European Inverter: 3-phase, 400 VAC,
3.7 kW, IEC IP20 standards
Fig 1.1 Nameplate
Inverter Model Numbers
The model number of the Inverter on the nameplate indicates the specification, voltage class, and maximum
motor capacity of the Inverter in alphanumeric codes.
Fig 1.2 Inverter Model Numbers
Table 1.2 Checks
Item Method
Has the correct model of Inverter been
delivered?
Check the model number on the nameplate on the side of the Inverter.
Is the Inverter damaged in any way?
Inspect the entire exterior of the Inverter to see if there are any scratches or
other damage resulting from shipping.
Are any screws or other components
loose?
Use a screwdriver or other tools to check for tightness.
Inverter model
Inverterspecifications
Mass
Input specification
Output specification
Serial number
UL file number
Lot number
MADE IN JAPAN
YASKAWA ELECTRIC CORPORARION
SPEC: 43P77A
PRG:
M
s
MASS: 4.0 kg
CIMR-L7Z43P7
AC3PH 380-480V 50/60Hz 10.2A
AC3PH 0-480V 0-120Hz 8.5A 3min. 50%ED 8.5kVA
FILE NO E131457
INPUT
OUTPUT
O/N
S/N
MODEL
CIMR – L7 Z 2 3P7
Inverter
Varispeed L7
No.
Z
Specification
OYMC European Std.
No.
Voltage Class
2
4
AC Input, 3-phase, 200 V
AC Input, 3-phase, 400 V
No.
Max. Motor Capacity
3P7
3.7 kW
5P5
5.5 kW
to
to
55
55 kW
“P” Indicates the decimal point.
