Omron VARISPEED L7 User Manual

5-61
5
 Settings which change with the Control Mode (A1-02)
Parameter
Number
Name Setting Range Unit
Factory Setting
V/f Control
A1-02=0
Open Loop
Vector
A1-02=2
Closed
Loop Vec-
tor A1-
02=3
Closed
Loop Vec-
tor (PM)
A1-02=5
C3-01 Slip compensation gain 0.0 to 2.5 - 1.0 1.0 1.0 1.0
C4-02 Torque compensation delay time 0 to 10000 msec 200 20 - -
C5-01 ASR P gain 1 1.00 to 300.00 - - - 40.00 12.00
C5-02 ASR Integral time 1 0.000 to 10.000 sec - - 0.500 0.300
C5-03 ASR P gain 2 1.00 to 300.00 - - - 20.00 6.00
C5-07 ASR gain switching frequency 0.0to 120.0
i
- - 0.0 Hz 2.0 %
C5-09 ASR P gain 3 1.00 to 300.00 - - - 40.00 12.00
C5-10 ASR Integral time 3 0.000 to 10.000 sec - - 0.500 0.300
E1-04 Max. Frequency
0 to 120.00 Hz Hz 50.00 50.00 50.00 -
20 to 7200 rpm rpm - - - 150
E1-06 Base Frequency
0 to 120.00 Hz Hz 50.00 50.00 50.00 -
20 to 7200 rpm rpm - - - 150
E1-08
Mid. output frequency voltage (VB)
*1
*1. The given values are for a 400 V class Inverter.
0.0 to 510.0 V 37.4 25.0 - -
E1-09 Min. output frequency (FMIN)
0 to 120.00 Hz Hz 0.5 0.3 0.0 -
20 to 7200 rpm rpm - - - 0
E1-10 Min. output frequency voltage (VMIN) 0.0 to 510.0 V 19.4 5.0 - -
E1-13 Base Frequency 0.0 to 510.0 V 0.0 0.0 - 400
E2-05 Mid. output frequency (FB) 0 to 120.00 Hz Hz 2.5 3.0 - -
E3-06
Mid. output frequency voltage (VB)
*1
0.0 to 510.0 V 30.0 26.4 - -
E3-07 Min. output frequency (FMIN) 0.0 to 120.0 Hz 1.2 0.5 0.0 -
E3-08
Min. output frequency voltage (VMIN)
*1
0.0 to 510.0 V 18.0 4.8 - -
F1-01 PG constant
0 to 60000 - - - 1024 -
512, 1024
*2
, 2048
*2. Can be set only if Hiperface is selected as interface.
- - - - 2048
F1-05 PG rotation direction 0 or 1 -
--0-
---1
F1-04 AO-12 Channel 1 Signal selection
1 to 56
-
222-
1 to 75 - - - 5
L1-01 Motor protection selection
0 to 3
-
111-
0 or 5 - - - 5
L4-01/03 Speed agreement detection level
0 to 120.00 Hz 0.0 0.0 0.0 -
0.0 to 100.0 % - - - 0.0
L4-02/04 Speed agreement detection width
0.0 to 20.0 Hz 2.0 2.0 2.0 -
0.0 to 40.o % - - - 4.0
L8-09 Output open phase detection selection
0 to 2 - 2 2 2 -
0 or 1 - - - - 0
n5-01 Feed forward control selection 0 or 1 - - - 1 0
o1-03 Frequency monitor/reference display 0 to 39999 - 0 0 0 1
o1-04 V/f pattern frequency parameter unit 0 or 1 - - - 0 1
S1-01 Zero speed level 0.00 to 10.00 Hz 1.2 0.5 0.1 0.5
