Installing and Wiring Option Cards
 Option Card Models and Specifications
Up to three option cards can be mounted simultaneously in the Inverter. Each of the three option board sockets
on the controller card (A, C and D) can take up one option card like shown in Fig 2.14.
Table 2.11 shows the available option cards and their specifications.
Table 2.11 Option Card Specifications
 Installation
Before mounting an Option Card, remove the terminal cover and be sure that the charge indicator inside the
Inverter is OFF. After that, remove the Digital Operator/LED Monitor and front cover and mount the Option
Card.
Refer to documentation provided with the Option Card for the mounting instructions.
Card Model Specifications
Mounting
Location
PG speed control cards
PG-B2
Two phase (phase A and B), +12V inputs, max.
response frequency: 50 kHz
A
PG-X2
Three phase (phase A, B, Z), line driver inputs
(RS422), max. response frequency: 300 kHz
A
PG-F2
Hiperface
y
or EnDat 2.1 interface card
A
Communications cards
3G3RV-PDRT2 Intelligent DeviceNet option card C
SI-P1 Option card for Profibus-DP fieldbus C
SI-R1 Option card for InterBus-S fieldbus C
SI-S1 Option card for CANOpen fieldbus C
S1-J Option card for LONworks C
PLC option card
3G3RV-P10ST8-E PLC option card C
3G3RV-P10ST8-DRT-E
PLC option card with DeviceNet communications
port (Slave)
C
Analog Input card AI-14B
3 Channel analog input card
Signal level: -10 to 10 V or 0 to 10V
Resolution: 13 Bit + sign
C
Analog Output Cards
AO-08
2 channel analog output card
Signal level: 0 to 10 V
Resolution: 8 Bit
D
AO-12
2 channel high resolution analog output card
Signal level: -10 to +10 V
Resolution: 11 Bit + sign
D
Digital Output Cards
DO-08
6 channel digital output card for monitoring the
inverter status (fault, zero speed, running, etc.)
D
DO-02C 2 channel relay contact output D
