6-28
6
 Limiting the Elevator Speed to the Leveling Speed (d1-17)
To use a high speed limit in the UP or DOWN direction to the leveling speed, one of the digital inputs must be
set to “High speed limit switch Up” or “High speed limit Down” (H1- = 87/88).
Multifunction Digital Inputs (H1-01 to H1-05)
High speed limit switch Up
The high speed limit switch UP function limits the speed to the leveling speed when the UP direction signal is
given. The DOWN direction has no speed limit.
High speed limit switch Down
The high speed limit switch DOWN function limits the speed to the leveling speed when the DOWN direction
signal is given, the UP direction has no speed limit.
Set Value Function
Control Methods
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop Vec-
tor (PM)
87 High speed limit switch (Up direction) Yes Yes Yes Yes
88 High speed limit switch (Down direction) Yes Yes Yes Yes
