Inverter Specifications
The Inverter specifications are listed in the following tables.
îš‹ Specifications by Model
Specifications are given by model in the following tables.
îš„200V Class
* 1. The maximum applicable motor output is given for a standard 4-pole Yaskawa standard motor. When selecting the actual motor and Inverter, be sure
that the Inverter's rated current is higher than the motor's rated current.
* 2. A transformer with dual star-delta secondary is required on the power supply for 12-pulse-rectification.
Table 9.1 200 V Class Inverters
Model Number
CIMR-L7Z

23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055
Max. applicable motor out-
put (kW)
*1
3.75.57.5111518.52230374555
Output Rating
Rated output capacity
(kVA)
7 10142027334054677693
Rated output current
(A)
17.5 25 33 49 64 80 96 130 160 183 224
Max. output voltage
(V)
3-phase; 200, 208, 220, 230, or 240 VAC
(Proportional to input voltage.)
Max. output frequency
(Hz)
Up to 120Hz available by programing.
Power supply characteristics
Rated voltage (V)
Rated frequency (Hz)
3-phase, 200/208/220/230/240 VAC, 50/60 Hz
Rated input current (A) 21 25 40 52 68 96 115 156 176 220 269
Allowable voltage fluc-
tuation
+ 10%, - 15%
Allowable frequency
fluctuation
±5%
Mea-
sures for
power
supply
DC reactor Optional Built In
12-pulse rec-
tification
Not possible Possible
