Omron VARISPEED L7 User Manual

5-44
5
 PM Motor Adjustments: n8 / n9
PM Motor Adjustment 1: n8
PM Motor Adjustment 2: n9
n5-05
Motor acceleration
time tuning
Enables or diables the tuning for
the motor acceleration time
N5-02.
0:Disabled
1:Enabled
0 or 1 0 No - - A A 5B4H 6-35
N5-02 Tuning
*1. The factory setting depends on the inverter capacity. The value for a 200 V Class Inverter of 3.7 kW is given.Automatic Frequency Regulator: n2
Con-
stant
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
Display V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
n8-29
Automatic Current
Regulator q axis P
gain
Sets the proportional gain for
the q-axis current regulator
(ACR)
0 to
2000
1000
rad/s
No - - - A 55CH 6-36
ACR q gain
n8-30
Automatic Current
Regulator q axis
integral time
Sets the integral time for the
q-axis current regulator
(ACR)
0 to
100.0
10.0 ms No - - - A 55DH 6-36
ACR q Itime
n8-32
Automatic Current
Regulator d axis P
gain
Sets the proportional gain for
d-axis current regulator
(ACR)
0 to
2000
1000
rad/s
No - - - A 55FH 6-36
ACR d gain
n8-33
Automatic Current
Regulator q axis
integral time
Sets the integral time for the
d-axis current regulator
(ACR)
0 to
100.0
10.0 ms No - - - A 560H 6-36
ACR d Itime
n8-35
Magnet position
detection method
Sets the magnet position detec-
tion method.
0:Estimate method
4:Hiperface detection
5:EnDat detection
0, 4 or
5
5No-- -Q5B0H
4-7
4-8
Mag det sel
n8-46
Inductance mea-
surement current
level
Sets the current which is used for
the inductance measurement dur-
ing rotating auto tuning. The
value is set in % of the motor
rated current.
0.0 to
99.9
10.0 % No - - - A .56DH -
Induct Meas Lev
n9-60
A/D conversion
start delay timer
Sets the A/D conversion delay
time.
0.0 to
40
0.0 µs No - - - A 64DH 6-37
AD DelayT@Start
Con-
stant
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
Display V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
