Omron VARISPEED L7 User Manual

5-32
5
 Terminal Function Parameters: H
Multi-function Digital Inputs: H1
Multi-function Digital Input Functions
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
H1-01
Terminal S3 func-
tion selection
Multi-function input 1 0 to 89 80 No A A A A 400H 6-50
Terminal S3 Sel
H1-02
Terminal S4 func-
tion selection
Multi-function input 2 0 to 89 84 No A A A A 401H 6-50
Terminal S3 Sel
H1-03
Terminal S5 func-
tion selection
Multi-function input 3 0 to 89 81 No A A A A 402H 6-50
Terminal S3 Sel
H1-04
Terminal S6 func-
tion selection
Multi-function input 4 0 to 89 83 No A A A A 403H 6-50
Terminal S3 Sel
H1-05
Terminal S7 func-
tion selection
Multi-function input 5 0 to 89 F No A A A A 404H 6-50
Terminal S3 Sel
Setting
Value
Function
Control Methods
Page
V/f
Open
Loop
Vec-
tor
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
3 Multi-step speed reference 1 Yes Yes Yes Yes 6-5
4 Multi-step speed reference 2 Yes Yes Yes Yes 6-5
5 Multi-step speed reference 3 Yes Yes Yes Yes 6-5
6 Jog frequency command (higher priority than multi-step speed reference) Yes Yes Yes Yes -
7 Accel/decel time 1 switch over Yes Yes Yes Yes 6-21
8 External baseblock NO (NO contact: Baseblock at ON) Yes Yes Yes Yes 6-50
9 External baseblock NC (NC contact: Baseblock at OFF) Yes Yes Yes Yes 6-50
F Not used (Set when a terminal is not used) - - -
14 Fault reset (Reset when turned ON) Yes Yes Yes Yes -
15 Emergency stop. (NO: Deceleration to stop in deceleration time set in C1-09 when ON.) Yes Yes Yes Yes 6-10
16 Motor 2 selection (NO: Motor 2 (E3- and E4-) is selected when ON.) Yes Yes Yes No 6-62
17 Emergency stop (NC: Deceleration to stop in deceleration time set in C1-09 when OFF) Yes Yes Yes Yes 6-10
18
Timer function input (the times are set in b4-01 and b4-02 and the timer function output is set
in H2-.)
Yes Yes Yes Ye s 6-52
1A Accel/decel time switch over 2 Yes Yes Yes Yes 6-21
20 to 2F External fault; Input mode: NO contact/NC contact, Detection mode: Normal/during operation Yes Yes Yes Yes 6-51
80 Nominal Speed Selection (d1-09) Yes Yes Yes Yes 6-7
81 Intermediate Speed Selection (d1-10) Yes No No No 6-7
82 Releveling Speed Selection (d1-13) Yes Yes Yes Yes 6-7
83 Leveling Speed Selection (d1-17) Yes Yes Yes Yes 6-7
84 Inspection Run Selection (d1-14) Yes Yes Yes Yes 6-11
85 Rescue Operation Selection Yes Yes Yes Yes 6-5
86 Motor Contactor Answer Back Signal Yes Yes Yes Yes 6-53
87 High Speed Limit Switch (UP) Yes Yes Yes Yes 6-28
