2.15
MAINTENANCE
2
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
Engine Intake Pre-Filter Service
It is recommended that the engine intake pre-filter be
inspected daily. The filter should be inspected using the
following procedure:
1. The engine intake pre-filter is located just above the
left rear wheel fender.
2. Press in on intake grill cover tab to access pre-filter.
3. Inspect the pre-filter. If necessary, clean with soapy
water and dry with low pressure compressed air.
Air Filter Service
Inspect the air filter at the intervals outlined in the Periodic
Maintenance Chart. In extremely dusty conditions, air filter
replacement will be required more often.
1. Remove the cargo box access panel (A).
2. Loosen the (5) air box cover retaining knobs (B) and
rotate them away from the cover. Release the (2)
cover latches (C).
3. Pull cover rearward far enough to remove air filter (D).
To Next Page
