2.24
MAINTENANCE
9924096 - 2013 RANGER RZR XP 900 / RZR XP 4 900 Service Manual
© Copyright 2012 Polaris Sales Inc.
35. Connect the negative (-) battery cable to the battery.
36. Start the engine to ensure proper operation.
37. Install the cargo box assembly (see Chapter 5).
38. Install the seats and engine service panel.
Exhaust - Spark Arrestor
Periodically clean spark arrestor to remove accumulated
carbon.
1. Remove the retaining screw and nut.
2. Remove the spark arrestor from the end of the
silencer.
3. Use a non-synthetic brush to clean the arrestor
screen. A synthetic brush may melt if components are
warm. If necessary, blow debris from screen with
compressed air.
4. Inspect the screen for wear and damage. Replace if
needed.
5. Reinstall the arrestor and torque the retaining screw
to 8 ft-lbs (11 Nm).
Do not clean spark arrestor immediately after
the engine has been run, as the exhaust system
becomes very hot. Serious burns could result
from contact with the exhaust components.
Allow components to cool sufficiently before
proceeding. Wear eye protection and gloves.
Never run the engine in an enclosed area.
Exhaust contains poisonous carbon monoxide
gas that can cause loss of consciousness
or death in a very short time.
Silencer
Arrestor
Screen
Nut
Screw
8 ft-lbs (11 Nm)
