quadient iX-9 Series User Manual

Changing Motorised Conveyor Stacker
Positions
11.13
The stacker can be installed in three positions:
• In line (0°)
• At +90°
• At -90°
The installation at -90° will be done by the technician who will
have to set the corresponding conveying speed and direction.
How to Install the Motorised Conveyor Stacker in Line (0°)
Assembly of the metallic attachment base
1. Position the flange of the two fixation holes as shown by the arrow.
360
| Page 360 | Jan-15-2024 09:55 |
11
Configuring your Mailing System
