Quantum Scalar i6000 User Manual

Chapter 2: Troubleshooting Your Library
Interpreting LEDs
106 Quantum Scalar i6000 User’s Guide
Figure 30 Locations of LBX
Terminator LEDs (Version 01)
Table 18 Explanations of LBX
Terminator LED States (Version
01)
1
2
3
4
LED On/Off Combinations
Explanation1 2 3 4
Off Off Off Off Robotics are disabled, the access door is open, or the LBX
terminator is misaligned.
On Off Off Off The library has one control module and no expansion modules.
On On Off Off The library has one control module and one expansion module.
On On On Off The library has one control module and two expansion modules.
On On On On The library has one control module and three expansion modules.
On Off On On The library has one control module and four expansion modules.
On On Off On The library has one control module and five expansion modules.
On Off On Off The library has one control module and six expansion modules.
On Off Off On The library has one control module and seven expansion modules.

Quantum Scalar i6000 Specifications

General

Form Factor	Rack-mountable
Interface	Fibre Channel, SAS
Product Type	Tape Library
Cooling	Redundant cooling fans
Dimensions	Varies by configuration
Weight	Varies by configuration
Operating Humidity	20% to 80% non-condensing
Scalability	Scalable
Drive Types	LTO
Redundancy	Redundant power supplies
Management	Web-based management
Tape Technology	LTO
Supported Media	LTO Ultrium 9, LTO Ultrium 8, LTO Ultrium 7, LTO Ultrium 6
Power Supply	Redundant power supplies
Non-operating Humidity	5% to 95% non-condensing
