8-60 Accessories
Antistatic Brush
Delivery Contents
•Antistatic Brush
• 2 Screws DIN7984-M4x6
• Washer DIN125-A4.3
Function
The antistatic brush is made to reduce electrostatic charges around the
printhead unit.
Mounting
1 Remove the rear cover.
2 Insert the screw (3) incl. washer (2) from the rear side into the drilling (1).
Note: This accessory is compatible only with the Pronto! 482 and 486 models.
Danger!: Risk of death via electric shock! Before opening the housing cover,
disconnect the device from the mains supply and wait at lease one minute
until the power supply unit has discharged.
Attention!: Do not insert screw (3) without washer (2). Otherwise the screw
(3) protruding through the chassis would hinder opening and closing the
printhead.
