12-14 Test functions
Te s t g r i d
1 Insert printable medium (labels, endless paper) which extends across the
entire printing width.
2 If the printout is to occur using thermal transfer printing, insert transfer
ribbon with the maximum width.
3 Press the menu button.
4 Select Test > Test grid menu.
5 Start printout with the ↵ button.
The geometric pattern is printed every 5 seconds once the Test grid function is
started. You can adjust the printer during the pauses between the printouts.
You can end the printout of the test grid with the cancel button.
The Test grid function prints out the geometric pattern on a
background grid. This allows you to assess the evenness of the
print quality.
The printout occurs using the heat level and print speed
specified in the Setup > Print param. menu.
Note: The printout occurs without taking the label gaps into consideration.
This is why endless media are most suitable for this purpose.
