Pronto! 482/486/682/863 6-5
• For use in Tear-Off mode only: Turn lever clockwise to lock the
printhead.
The label roll is loaded for use in Tear-Off mode.
Winding up the label strip in Rewind mode
In Rewind mode, the labels are wound up internally after printing for later
use.
1 Remove the locking system for Rewind mode if necessary (see Removing
and installing the locking system on page 6-13) and install rewind guide
plate (see Removing and installing the rewind guide plate, dispense plate or
tear-off plate on page 6-12).
2 Guide label strip around the rewind guide plate (4) to the internal
rewinder (2).
2 13
5
4
