Paper Transfer
G133 3-46 SM
After installing a new ID sensor unit/board
Do the following adjustment after installing a new ID sensor unit/board.
1. Plug in and turn on the main power switch of the mainframe.
2. Enter the SP mode.
3. Input all correction coefficients [A] for the ID sensor with the SP modes referring to the
barcode sheet provided with the new ID sensor unit/board.
For example, input "1.00" with SP3-362-013.
4. Exit the SP mode.
3.8.5 TEMPERATURE AND HUMIDITY SENSOR
1. Rear cover ( "p.3-3 "Rear Cover"")
2. Right rear cover (
"p.3-3 "Right Rear Cover"")
3. Temperature and humidity sensor [A] ( x 1, x 1)
