T
ray Exit Sensor
SM 3
B227
B227
Bridge Unit
1.3
TRAY EXIT SENSOR
1. Bridge
unit
(
Inst
allation Procedure in the base copier manual)
2.
Rear cover ("Rear Cover")
3.
Paper tray [A]
4.
Exit guide [B] (
x 1)
5.
T
ray exit sensor [C] (
x 1)
792
