Punch Unit (B702)
SM 1-39
G133
Inst
allation
1.8 PUNCH
UNIT
(B702)
The Punch Unit "B702" is used fo
r the 3000 Sheet Finisher (B805).
1.8.1 COMPONENT
CHECK
Check the quantity and condi
tion of the components against the following list.
No.
Description
Q’ty
1
Punchout W
aste Unit
1
2
Slide Drive Unit
1
3
Punch W
aste Hopper
1
4
Screws (M3 x 6)
5
5 Side-to-Side
Detection
Unit
1
6 Punching
Unit
1
1.8.2 INSTALLATION
PROCEDURE
Unplug the main machine power cord before starting the follo
w
ing
