Junction Gates
SM 39
B793
B793
Booklet
Finisher
2.2 JUNCTION
GATES
T
wo junction gates contro
l the pa
th of paper
.
Each junction gate is controlled by a solenoid.
Junction gate operation
is summarized in the following table.
Mode
Proof
Shift
S
taple
Paper Path
Proof T
ray
Gate Solenoid
ON OFF
OFF
S
taple T
ray
Gate Solenoid
OFF OFF
ON
844
