Duplex Unit
SM 3-101
G133
Repla
cement
Adjustment
6.
Wire [D] (
x 1)
7.
Duplex unit [E] (
x 1, S
tud screw x 1,
=
x 1,
x 3, ground cable x 1)
3.12.2 DUPLEX
DOOR
SENSOR
1.
Right door cover (
"p.3-3 "Duplex Unit"")
2.
Open the right door
.
3.
Duplex door sensor [A] (
x 1, hook)
3.12.3
DUPLEX ENTRANCE SENSOR
1.
Right door cover (
"p.3-3 "Duplex Unit"")
2.
Open the right door
.
198
200
