Electrical Components
G133 3-1
16
SM
the SMC sheets that have been printed out.
3.
Select the destination area with SP5-807-001.
SP5-807-001 is an SSP
, so please consult your supervisor
.
4.
Input the serial number of the machine with SP5-81
1-00
1.
5.
Only when installing an NVRAM on the
controller board
, specify the brand name with
SP5-907-001.
6.
Exit the SP mode, and turn the main power switch of
f and on.
213
215
