Service Program Mode
SM 5-3 G133
Service
Tables
Paper Weight
Thin paper: 52-59 g/m
2
Plain Paper: 60-81g/m2, 16-22lb.
Middle Thick: 82-105g/m2, 22-28lb.
Thick Paper 1: 106-169g/m2, 28.5-44.9lb.
Thick Paper 2: 170-219g/m2, 45-58lb.
Thick Paper 3: 220 – 253 g/m
2
, 58 – 67 lb.
Paper Type
N: Normal paper
MTH: Middle thick paper
TH: Thick paper
Paper Feed Station
P: Paper tray (numbered from 1 to 5, top to
bottom)
B: By-pass table
Color Mode [Color]
[K]: Black in B&W mode
[Y], [M], or [C]: Yellow, Magenta, or Cyan in Full Color mode
[YMC]: Only for Yellow, Magenta, and Cyan
[FC]: Full Color mode
[FC, K], [FC, Y], [FC, M], or [FC, C]: Black, Yellow, Magenta, or Cyan in full color mode
Print Mode
S: Simplex
D: Duplex
Process Speed
L: Low speed (77 mm/s)
M: Middle speed (115 mm/s)
H: High speed (205 mm/s)
Others
The following symbols are used in the SP mode tables.
FA: Factory setting
(Data may be adjusted from the default setting at the factory. Refer to the factory setting
sheets enclosed. You can find it under the jammed paper removal decal.)
DFU: Design/Factory Use only
Do not touch these SP modes in the field.
A sharp (#) to the right hand side of the mode number column means that the main switch
must be turned off and on to effect the setting change.
An asterisk (*) to the right hand side of the mode number column means that this mode is
stored in the NVRAM. If you do a RAM clear, this SP mode will be reset to the default value.
“ENG” and “CTL” show which NVRAM contains the data.
