Service Mode Table
SM 5-305 G133
Service
Tables
detected
5803 79 Duplex Exit Sensor Paper detected
Paper not
detected
5803 80 Duplex Open/Closed Detection Closed Open
5803 81 Duplex Feed Cover Open Closed
5803 82 1 Bin Tray Set Detection Set Not set
5803 83 1 Bin Tray Sensor Paper detected
Paper not
detected
5803 87 Bank Vertical Transport Sensor 3
Paper not
detected
Paper detected
5803 88 Bank Vertical Transport Sensor 4
Paper not
detected
Paper detected
5803 89 Bank Feed Sensor 3
Paper not
detected
Paper detected
5803 90 Bank Feed Sensor 4
Paper not
detected
Paper detected
5803 91 Bank Relay Cover Detection Closed Open
5803 92 Bank Vertical Transport Sensor 5 Not used
5803 93 Bank Feed Sensor 5 Not used
5803 94 GAVD Open/Closed Detection
Closed (LD5V
ON)
Open
(LD5V OFF)
5803 96 New Transfer Detection Not new New
5803 101 PP: D: SC Detection SC detected No SC
5803 102 PP: CB: SC Detection SC detected No SC
5803 103 PP: TTS: SC Detection SC detected No SC
5803 104 Fusing Coil Fan: Lock Normal Lock error
