Paper Feed
SM 6-53 G133
Detailed
Descriptions
end) is for tray set detection. The other three switches detect the paper size as shown in
the table below. The actuator [B] is moved by the end plate [C].
0: Pushed, 1: Not pushed
Models Switch Location
North America Europe/Asia SW4 SW3 SW2
DLT (A3) SEF*
1
A3 (DLT) SEF*
1
0 0 1
LG (B4) SEF*
2
B4 (LG) SEF*
2
0 0 0
A4 SEF A4 SEF 1 1 0
LT SEF LT SEF 1 1 1
B5 SEF B5 SEF 0 1 1
LT (A4) LEF*
3
A4 (LT) LEF*
3
1 0 0
Exe (B5) LEF*
4
B5 (Exe) LEF*
4
0 1 0
A5 LEF A5 LEF 1 0 1
*1: The machine detects either DLT SEF or A3 SEF, depending on the setting of
SP5-181-3.
*2: The machine detects either LG SEF or B4 SEF, depending on the setting of
SP5-181-4.
*3: The machine detects either LT LEF or A4 LEF, depending on the setting of
SP5-181-2.
*4: The machine detects either Exe LEF or B5 LEF, depending on the setting of
SP5-181-5
SP 5-181-6 to –13 does similar functions for the optional paper trays.
The machine disables paper feed from a tray if the paper size cannot be detected (if the
paper size actuator is broken or no tray is installed).
For non-standard paper sizes, if they are not visible on the user tool screen for selecting
paper sizes, then set SP 5112 to "1". If the user selects one of these sizes, auto paper size
selection is disabled.
