DIP Switches
SM 27 B793
B793
Booklet
Finisher
1.5 DIP SWITCHES
SW100: Adjust the staple position for booklet mode
No. Function
1 ON: 0.3 mm
2 ON: 0.6 mm
3 ON: 1.2 mm
4
Direction
OFF: Towards the trailing edge, ON: Towards the leading edge
SW101: Adjust the fold position
No. Function
1 ON: 0.2 mm
2 ON: 0.4 mm
3 ON: 0.8 mm
4
Direction
OFF: Towards the trailing edge, ON: Towards the leading edge
SW102: Move the tray position
No. Function
1
OFF → ON → OFF
Turn the switch from off to on, then turn it to off again. Then, the tray moves down to
the shipping position
2 Not used
After you change any of these dip switch settings, open and close the finisher
cover to activate the new setting. It is not necessary to turn the main power off/on.
