Fusing

SM 3-43 G179

Replacement

Adjustment

 The cords on this frame are still connected to the fusing unit at this time. Be

careful not to damage the cords when removing the hot roller stripper [B].

5. Hot roller stripper [B] (spring x 1)

3.9.9 FUSING LAMPS

1. Fusing unit ( Fusing Unit)

2. Web roller unit ( Web Roller Unit)

3. Fusing top cover ( Thermostat)

4. Connector cover [A] ( x 2)

5. Fusing top frame with connector [B] ( x 9)

6. Fusing front lower cover [C] ( x 2)
