Output Jogger Unit (B703)
SM 1-27 G179
Installation
1.8 OUTPUT JOGGER UNIT (B703)
1.8.1 ACCESSORIES
Check the accessories and their quantities against this list.
Description Qty
1. Jogger Unit 1
2. Tapping Screws M3x6 2
1.8.2 INSTALLATION
The Output Jogger Unit B703 is installed only on the 3000-Sheet Finisher B805.
Always switch the machine off and unplug the machine before doing any of the
following procedures
1. Turn the main machine switch off.
2. Disconnect the finisher from the main frame.
To Next Page
