Ricoh G179 User Manual

Corner Stapling
SM 51 B804/B805
Booklet
Finisher/
Finisher
B804/B805
The stapler performs horizontal and rotational movement in each of the four staple modes:

Front 1 staple

Rear 1 staple

Rear diagonal staple

Rear/Front 2 staples
The stapler movement motor [A] drives a timing belt that moves stapler [B] left and right on
its stainless steel rail.
The stapler rotation motor [C] rotates the stapler into position for diagonal stapling at the
rear.

The stapler movement motor switches on and moves the stapler the standby stapling
position. (This is the stapling position for the paper size selected for the job.)

The stapler movement motor switches off and the stapler waits for the signal to fire (or
swivel and for diagonal stapling).
If the stack is to be stapled at two positions:

The stapler movement motor moves the stapler to the front position and staples the
front.

The stapler movement motor moves the stapler to the rear and the stapler staples the
rear.
If the stack is stapled at the rear with a diagonal staple, the staple moves to the rear. When it
is time for stapling, the rotation motor rotates the stapler to the correct angle and holds the
stapler in that position while the stapler fires.
The stapling positions can be fine adjusted with SP6-133-001.
