Electrical Components
D353 8 SM
3. Rear ground plate [A] ( x 1)
4. Front ground plate [B] ( x 1)
5. Paper feed unit [C] ( x 2, = x 1,  x 1)
6. Paper feed unit cover [D] ( x 5,  x 1)
 Before you re-install the paper feed unit cover, make sure that the pick-up
solenoid holds the pick-up roller lever ([a]: correct, [b]: incorrect) and the
pick-up roller works properly.
