MFX/IFX Parameters
Parameter Value Explanation
Level 0–127 Output Level
84 Saturator
This eect combines overdrive and lter.
Balance W
Balance D
Balance D
Pre FilterPre Filter
OverdriveOverdrive
Post Filter1-3Post Filter1-3
Pre FilterPre Filter
OverdriveOverdrive
Post Filter1-3Post Filter1-3
L in L out
R outR in
Parameter Value Explanation
DrvPre1 Type
THRU, LPF, HPF, LSV,
HSV
Type of lter that precedes the distortion
processing
THRU: No lter is applied
LPF: A lter that passes the sound below the
specied frequency
HPF: A lter that passes the sound above the
specied frequency
LSV: A lter that boosts/cuts the sound below
the specied frequency
HSV: A lter that boosts/cuts the sound above
the specied frequency
DrvPre1 Frequency 20–16000 [Hz]
Frequency at which the pre-distortion lter
operates
DrvPre1 Gain -24.0–+24.0 [dB]
For the LSV/HSV types, the amount of boost/
cut
Drive 0.0–+48.0 [dB] Strength of distortion
DrvPost1 Type
THRU, LPF, HPF, LSV,
HSV
Type of lter 1 which follows the distortion
processing
DrvPost1 Frequency 20–16000 [Hz]
Frequency at which post-distortion lter 1
operates
DrvPost1 Gain -24.0–+24.0 [dB]
For the LSV/HSV types, the amount of boost/
cut
DrvPost2 Type
THRU, LPF, HPF, LSV,
HSV
Type of lter 2 which follows the distortion
processing
DrvPost2 Frequency 20–16000 [Hz]
Frequency at which post-distortion lter 2
operates
DrvPost2 Gain -24.0–+24.0 [dB]
For the LSV/HSV types, the amount of boost/
cut
DrvPost3 Type
THRU, LPF, HPF, BPF,
PKG
Type of lter 3 which follows the distortion
processing
THRU: No lter is applied
LPF: A lter that passes the sound below the
specied frequency
HPF: A lter that passes the sound above the
specied frequency
BPF: A lter that passes only the specied
frequency
PKG: A lter that boosts/cuts the specied
frequency
DrvPost3 Frequency 20–16000 [Hz]
Frequency at which post-distortion lter 3
operates
DrvPost3 Gain -24.0–+24.0 [dB] For the PKG type, the amount of boost/cut
DrvPost3 Q 0.5–16.0
Width of the frequency range aected by the
lter
Makeup Sense -60.0–0.0 [dB]
Adjust this value so that the sound is not
made louder when distortion is applied.
DrvPost Gain -48.0–+12.0 [dB] Gain following distortion processing
Drive Balance D100:0W–D0:100W
Volume balance between the dry sound (D)
and eect sound (W)
Level 0–127 Output Level
85 Warm Saturator
This is a variety of saturator, and is distinctive for its warmer sound.
Balance W
Balance D
Balance D
Pre FilterPre Filter
OverdriveOverdrive
Post
Filter1-3
Post
Filter1-3
Pre FilterPre Filter
Low/HighLow/High
Low/HighLow/High
OverdriveOverdrive
Post
Filter1-3
Post
Filter1-3
L in L out
R outR in
Parameter Value Explanation
EQ Low Frequency 20–16000 [Hz]
Input lter (low range)
Boosts/cuts the sound below the specied
frequency.
EQ Low Gain -24–+24 [dB] Amount of boost/cut
EQ High Slope THRU, -12dB, -24dB
Input lter (high range)
Boosts/cuts the sound above the specied
frequency.
EQ High Frequency 20–16000 [Hz] Amount of boost/cut
DrvPre1 Type
THRU, LPF, HPF, LSV,
HSV
Types of lter that precedes the distortion
processing
THRU: No lter is applied
LPF: A lter that passes the sound below the
specied frequency
HPF: A lter that passes the sound above the
specied frequency
LSV: A lter that boosts/cuts the sound below
the specied frequency
HSV: A lter that boosts/cuts the sound above
the specied frequency
DrvPre1 Frequency 20–16000 [Hz]
Frequency at which the pre-distortion lter
operates
DrvPre1 Gain -24.0–+24.0 [dB]
For the LSV/HSV types, the amount of boost/
cut
Drive 0.0–+48.0 [dB] Strength of distortion
DrvPost1 Type
THRU, LPF, HPF, LSV,
HSV
Type of lter 1 which follows the distortion
processing
DrvPost1 Frequency 20–16000 [Hz]
Frequency at which post-distortion lter 1
operates
DrvPost1 Gain -24.0–+24.0 [dB]
For the LSV/HSV types, the amount of boost/
cut
DrvPost2 Type
THRU, LPF, HPF, LSV,
HSV
Type of lter 2 which follows the distortion
processing
DrvPost2 Frequency 20–16000 [Hz]
Frequency at which post-distortion lter 2
operates
DrvPost2 Gain -24.0–+24.0 [dB]
For the LSV/HSV types, the amount of boost/
cut
DrvPost3 Type
THRU, LPF, HPF, LSV,
HSV
Type of lter 3 which follows the distortion
processing
THRU: No lter is applied
LPF: A lter that passes the sound below the
specied frequency
HPF: A lter that passes the sound above the
specied frequency
BPF: A lter that passes only the specied
frequency
PKG: A lter that boosts/cuts the specied
frequency
DrvPost3 Frequency 20–16000 [Hz]
Frequency at which post-distortion lter 3
operates
DrvPost3 Gain -24.0–+24.0 [dB] For the PKG type, the amount of boost/cut
DrvPost3 Q 0.5–16.0
Width of the frequency range aected by the
lter
Makeup Sense -60.0–0.0 [dB]
Adjust this value so that the sound is not
made louder when distortion is applied.
DrvPost Gain -48.0–+12.0 [dB] Gain following distortion processing
