Roland Groovebox MC-707 User Manual

12
Basic Operation
Importing a Clip
1.
Move the cursor to the position at which you want to import
a clip.
2.
Press the [CLIP] button.
The clip browser shows the projects that are in the SD card.
3.
When you use the cursor buttons to select a project, the
clips inside it are shown.
* Clips of the same type as the track type of the currently selected track are
shown.
4.
Use the cursor buttons to select the clip that you want to
import, and then press the [ENTER] button.
The clip is imported.
Importing might take some time.
When importing is completed, you return to the home screen.

Roland Groovebox MC-707 Specifications

General

Product color	Black
USB direct playback	-
Built-in optical drive	No
USB port	Yes
USB connector type	USB Type-B
USB ports quantity	1
Compatible memory cards	SD, SDHC
Display type	LCD
Display resolution	256 x 80 pixels
Current	2 A
Power supply type	AC

Weight and Dimensions

Depth	263 mm
Width	426 mm
Height	60 mm
Weight	2100 g
