MFX/IFX Parameters
25 Step Flanger
This is a anger in which the anger pitch changes in steps.
The speed at which the pitch changes can also be specied in terms of
a note-value of a specied tempo.
R out
L out
2-Band EQ2-Band EQ
2-Band EQ2-Band EQ
Balance W
Balance W
Feedback
Feedback
Balance D
Balance D
L in
Step FlangerStep Flanger
Step FlangerStep Flanger
R in
Parameter Value Explanation
Filter Type OFF, LPF, HPF
Type of lter
OFF: No lter is used.
LPF: Cuts the frequency range above the
Cuto Freq
HPF: Cuts the frequency range below the
Cuto Freq
Cuto Freq
200, 250, 315, 400,
500, 630, 800, 1000,
1250, 1600, 2000,
2500, 3150, 4000,
5000, 6300, 8000 [Hz]
Basic frequency of the lter
Pre Delay 0.0–100.0 [msec]
Adjusts the delay time from the direct sound
until the anger sound is heard.
Rate
(sync sw) OFF, ON
If this is ON, the rate synchronizes with the
tempo of the rhythm.
&
“TEMPO” (p. 52)
Rate (Hz) 0.05–10.00 [Hz]
Frequency of modulation
Rate
(note)
Note
&
“Note” (p. 120)
Depth 0–127 Depth of modulation
Phase 0–180 [deg] Spatial spread of the sound
Feedback -98–+98 [%]
Adjusts the proportion of the anger sound
that is fed back into the eect. Negative (-)
settings will invert the phase.
Step Rate
(sync sw) OFF, ON
If this is ON, the rate synchronizes with the
tempo of the rhythm.
&
“TEMPO” (p. 52)
Step Rate (Hz) 0.10–20.00 [Hz]
Rate (period) of pitch change
Step Rate
(note)
Note
&
“Note” (p. 120)
Low Gain -15–+15 [dB] Gain of the low range
High Gain -15–+15 [dB] Gain of the high range
Balance D100:0W–D0:100W
Volume balance between the direct sound (D)
and the anger sound (W)
Level 0–127 Output Level
26 Hexa-Chorus
Uses a six-phase chorus (six layers of chorused sound) to give richness
and spatial spread to the sound.
R out
L out
Balance W
Balance W
Balance D
Balance D
L in
Hexa ChorusHexa Chorus
R in
Parameter Value Explanation
Pre Delay 0.0–100 [msec]
Adjusts the delay time from the direct sound
until the chorus sound is heard.
Rate
(sync sw) OFF, ON
If this is ON, the rate synchronizes with the
tempo of the rhythm.
&
“TEMPO” (p. 52)
Rate (Hz) 0.05–10.00 [Hz]
Frequency of modulation
Rate
(note)
Note
&
“Note” (p. 120)
Depth 0–127 Depth of modulation
Pre Delay Deviation 0–20
Adjusts the dierences in Pre Delay between
each chorus sound.
Depth Deviation -20–20
Adjusts the dierence in modulation depth
between each chorus sound.
Pan Deviation 0–20
Adjusts the dierence in stereo location
between each chorus sound.
0: All chorus sounds will be in the center.
20: Each chorus sound will be spaced at 60
degree intervals relative to the center.
Balance D100:0W–D0:100W
Volume balance between the direct sound (D)
and the chorus sound (W)
Level 0–127 Output Level

Roland Groovebox MC-707 Specifications

General

Product color	Black
USB direct playback	-
Built-in optical drive	No
USB port	Yes
USB connector type	USB Type-B
USB ports quantity	1
Compatible memory cards	SD, SDHC
Display type	LCD
Display resolution	256 x 80 pixels
Current	2 A
Power supply type	AC

Weight and Dimensions

Depth	263 mm
Width	426 mm
Height	60 mm
Weight	2100 g
