89
MFX/IFX Parameters
11 Phaser 1
This is a stereo phaser. A phase-shifted sound is added to the original
sound and modulated.
R outR in
Mix
L in L out
Mix
Parameter Value Explanation
Mode
4-STAGE, 8-STAGE,
12-STAGE
Number of stages in the phaser
Manual 0–127
Center frequency at which the sound is
modulated
Rate
(sync sw) OFF, ON
If this is ON, the rate synchronizes with the
tempo of the rhythm.
&
“TEMPO” (p. 52)
Rate (Hz) 0.05–10.00 [Hz]
Modulation rate
Rate
(note)
Note
&
“Note” (p. 120)
Depth 0–127 Depth of modulation
Polarity INVERSE, SYNCHRO
Selects whether the left and right phase
of the modulation will be the same or the
opposite.
INVERSE: The left and right phase will be
opposite.
When using a mono source, this spreads the
sound.
SYNCHRO: The left and right phase will be
the same.
Select this when inputting a stereo source.
Resonance 0–127 Amount of feedback
Cross Feedback -98–+98 [%]
Adjusts the proportion of the phaser sound
that is fed back into the eect. Negative (-)
settings will invert the phase.
Mix 0–127 Level of the phase-shifted sound
Low Gain -15–+15 [dB] Gain of the low range
High Gain -15–+15 [dB] Gain of the high range
Level 0–127 Output Level
12 Phaser 2
This simulates an analog phaser of the past.
It is particularly suitable for electric piano.
L in L out
R outR in
Parameter Value Explanation
Rate 0–100 Modulation rate
Color 1, 2 Modulation character
Low Gain -15–+15 [dB] Gain of the low range
High Gain -15–+15 [dB] Gain of the high range
Level 0–127 Output Level
13 Phaser 3
This simulates a dierent analog phaser than Phaser 2.
It is particularly suitable for electric piano.
L in L out
R outR in
Parameter Value Explanation
Speed 0–100 Speed of modulation
Depth 0–127 Depth of modulation
Low Gain -15–+15 [dB] Gain of the low range
High Gain -15–+15 [dB] Gain of the high range
Level 0–127 Output Level
