Table 10. Status Word 1
Field Bits
Comments
0
Interleave
switch
ON
1-3
Memory
unit
size:
000
8K
001
16K
010·
24K
011 32K
100
40K
101
48K
110
56K
111
64K
4-6
Memory
unit
number (binary code)
Starting
7
Starting
address
bit
12
Address
8
Starting
address
bit
13
9
Starting
address
bit
14
10
Starting
address
bit
15
11
Starting
address
bit
16
12
Starting address
bit
17
13
Starting
address
bit
18
14
Reserved
15-31
Address
received,
bits 15-31
WAIT
WAIT
(Word index
al
ignment,
privileged)
WAIT
causes
the
basic
processor to
cease
all
operations
until
an
interrupt
activation
occurs,
or
until
the
operator
puts
the
basic
processor
in
the
IDLE
mode and then
back
to
RUN
(see
Chapter
5).
The instruction address portion
of
the
PSWs
is
updated
before the basic processor begins waiting;
there-
fore,
while
it
is
waiting,
the
INSTRUCTION
ADDRESS
indi-
cators
contain
the
virtual address
of
the
next
location
in
ascending
sequence
after
WAIT
and
the
contents in
the
next
location
are
displayed
in
the
DISPLAY
indicators on
the
processor control console. If
any
input/output
operations
are
being
performed when
WAIT
is
executed,
the
operations
proceed
to
their
normal
termination.
When
an
interrupt
activation
occurs
while
the
basic
pro-
cessor is
waiting,
it processes
the
interrupt-servicing
routine.
Normally,
the
interrupt-servicing
routine
begins with
an
XPSD
instruction in
the
interrupt
location,
and ends with
an
LPSD
instruction
at
the
end
of
the
routine.
After
the
LPSD
instruction is
executed,
the
next
instruction to
be
ex-
ecuted
in
the
interrupted program is
the
next
instruction in
sequence
after
the
WAIT
instruction.
If
the
interrupt
is to a
single-instruction
interrupt
location,
the
instruction in
the
interrupt
location
is
executed
and
then
instruction
execution
proceeds with
the
next
instruction in
sequence
after
the
WAIT
instruction.
When
the
basic
processor
execution
mode
is
changed from
RUN
mode
to
IDLE
mode and
back
to
RUN
while
the
basic
processor
is
waiting,
instruction
execution
proceeds with
the
next
instruction in
sequence
after
the
WAIT
instruction.
Affected:
PC
If
WAIT
is
indirectly
addressed
and
the
indirect
reference
address
is
nonexistent,
the
nonallowed
operation
trap
to
location
X'40'
will not
occur.
The
effective
virtual address
of
the
WAIT
instruction,
however,
is
not used
as
a memory
reference
(thus does not
affect
the
norma I
operation
of
the
instruction).
RD
READ
DIRECT
(Word
index
alignment,
privileged)
The
basic
processor
is
capable
of
directly
communicating
with
other
elements
of
the
system, as well
as
performing
internal
control
operations,
by means of
the
READ
DIRECT
/
WRITE
DIRECT
(RD/WD) lines. The RD/WD lines consist of
16
address
lines,
32
data
lines,
two
condition
code
lines,
and
various control
lines
that
are
connected
to
various
basic
processor
circuits
and
to
special
system
equipment.
READ
DIRECT
causes bits
16
through
31
of
the
effective
virtual
address
to
be
presented
to
other
elements
of
the
sys-
tem on
the
RD/WD address lines. Bits 16-31
of
the
effective
virtual address
identify
a
specific
elementof
the
system
that
is
expected
to
return information (two
condition
code
bits
plus a maximum of
32
data
bits) to
the
basic
processor. The
sign ifi
cance
and
number
of
data
bits returned
depend
on
the
selected
element.
If
the
R
field
of
RD
is
nonzero,
up to
32
bits
of
the
returned
data
are
loaded into
general
regis-
ter
R;
however,
if
the
R field
of
RD
is
0,
the
returned
data
is
ignored
and
general
register
0
is
not
changed.
Bits
CC3
and
CC4
of
the
condition
code
are
set
by
the
addressed
element,
regardless
of
the
value
of
the
R
field.
Bits
16-19
of
the
effective
virtual
address
of
RD
determine
the
mode
of
the
RD
instruction,
as follows:
Bit Position
16 17 18 19
Mode
o 0 0 0 Interna I basi c processor
control.
000
Interrupt
control.
000
Xerox testers.
Control Instructions 103
