significance (FS), floating zero (FZ), and floating normalize
(FN) mode control bits, respectively (in the program status
words); however, if bit 11 is 0, the FR, FS, FZ, and FN
control bits are not affected. The functions of the floating-
point control bits are described in the section "Floating-
Point Arithmetic Instructions".
Affected: CC, FR, FS, FZ, FN
If (1)10
= 1, (1)24-27 -CC
If (1)10 = 0, CC is not affected.
Trap: Nonexistent in-
struction, if bit °
is a 1.
If (1)11 = 1, (1)28-31 -FR, FR, FS, FZ, FN
If
(1)11 = 0, FR, FS, FZ, and FN not affected.
Condition code settings, if (1)10 = 1:
2
3
4
(1)24
(1)27
If
LCFI is indirectly addressed, it is treated as a nonexistent
instruction, in which case the computer unconditionally
aborts execution of the instruction (at the time of operation
code decoding) and traps to location X'40' with the condi-
tion code unchanged.
LCF
LOAD CONDITIONS AND FLOATING
CONTROL
(Byte index alignment)
If bit position 10 of the instruction word contains a 1,
LOAD CONDITIONS AND FLOATING CONTROL loads
bits ° through 3 of the effective byte into the condition
code; however, if bit 10 is 0, the condition code is not
affected.
If bit position 11 of the instruction word contains a 1, LCF
loads bits 4 through 7 of the effective byte into the floating
round (FR), floating significance (FS), floating zero (FZ),
and floating normalize (FN) mode control bits, respectively;
however, if bit 11 is 0, the FR, FS, FZ, and FN control
bits are not affected. The functions of the floating-point
mode control bits are described in the section "Floating-
Point Arithmetic Instructions".
Affected: CC, FR, FS, FZ, FN
If 0)10 = 1, EB
O
_
3
-CC
If (1) 10 = 0, CC not affected
If (1)11 = 1, EB 4-7 - FR, FS, FZ, FN
If (I) 11 = 0, FR, FS, FZ, FN not affected
54 Load/Store Instructions
Condi ti on
code setti ngs, if (I) 10 = 1:
2
3 4
(EB)O
(EB) 1
LVAW LOAD VIRTUAL ADDRESS WORD
(Word index alignment)
H 34 I R I X I: Reference>ddress I
o J 2 314 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19120 21 22 23 24 25 26 27128 29 30 31
LOAD VIRTUAL ADDRESS WORD loads bit positions 15-31
of register R with the effective virtual word address of the
instruction whi Ie bit positions 0-14 of register R are cleared
to zero.
Affected: (R)
EVA -R
15
-
31
,
O-R
O
_
14
Note: Condition code is not affected by LVAW.
xw
EXCHANGE WORD
(Word index alignment)
EXCHANGE WORD exchanges the contents of register R
wi th
the contents of the effecti ve word location.
Affected: (R), (EWL), CC3, CC4
(R)-(EWL)
Condition code settings:
2 3
4
Result in R
- -
° °
Zero
-
-
°
Negative
°
Positive
STB
STORE BYTE
(Byte index alignment)
STORE BYTE stores the contents of bit positions 24-31 of
register R into the effective byte location.
Affected: (EBL)
(R)24-31 - EBL
