Xilinx KC705 User Manual

KC705 Evaluation Board 47
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
HDMI Video Output
[Figure 1-2, callout 18]
The KC705 board provides a High-Definition Multimedia Interface (HDMI) video output
using the Analog Devices ADV7511KSTZ-P HDMI transmitter (U65). The HDMI output is
provided on a Molex 500254-1927 HDMI type-A connector (P6). The ADV7511 is wired to
support 1080P 60Hz, YCbCr 4:2:2 encoding via 16-bit input data mapping.
The KC705 board supports the following HDMI device interfaces:
• 18 data lines
•Independent VSYNC, HSYNC
• Single-ended input CLK
• Interrupt Out Pin to FPGA
•I2C
•SPDIF
