Xilinx KC705 User Manual

KC705 Evaluation Board 49
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
Table 1-21 lists the connections between the codec and the FPGA.
Table 1-21: FPGA to HDMI Codec Connections (ADV7511)
U1 FPGA Pin Schematic Net Name I/O Standard
ADV7511 (U65)
Pin Number Pin Name
B23 HDMI_D0 LVCMOS25 88 D8
A23 HDMI_D1 LVCMOS25 87 D9
E23 HDMI_D2 LVCMOS25 86 D10
D23 HDMI_D3 LVCMOS25 85 D11
F25 HDMI_D4 LVCMOS25 84 D12
E25 HDMI_D5 LVCMOS25 83 D13
E24 HDMI_D6 LVCMOS25 82 D14
D24 HDMI_D7 LVCMOS25 81 D15
F26 HDMI_D8 LVCMOS25 80 D16
E26 HDMI_D9 LVCMOS25 78 D17
G23 HDMI_D10 LVCMOS25 74 D18
G24 HDMI_D11 LVCMOS25 73 D19
J19 HDMI_D12 LVCMOS25 72 D20
H19 HDMI_D13 LVCMOS25 71 D21
L17 HDMI_D14 LVCMOS25 70 D22
L18 HDMI_D15 LVCMOS25 69 D23
K19 HDMI_D16 LVCMOS25 68 D24
K20 HDMI_D17 LVCMOS25 67 D25
H17 HDMI_DE LVCMOS25 97 DE
J17 HDMI_SPDIF LVCMOS25 10 SPDIF
K18 HDMI_CLK LVCMOS25 79 CLK
H20 HDMI_VSYNC LVCMOS25 2 VSYNC
J18 HDMI_HSYNC LVCMOS25 98 HSYNC
AH24 HDMI_INT LVCMOS25 45 INT
G20 HDMI_SPDIF_OUT LVCMOS25 46 SPDIF_OUT
