KC705 Evaluation Board 6
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1
KC705 Evaluation Board Features
Overview
The KC705 evaluation board for the Kintex®-7 FPGA provides a hardware environment for
developing and evaluating designs targeting the Kintex-7 XC7K325T-2FFG900C FPGA. The
KC705 board provides features common to many embedded processing systems, including
a DDR3 SODIMM memory, an 8-lane PCI Express® interface, a tri-mode Ethernet PHY,
general purpose I/O, and a UART interface. Other features can be added by using FPGA
Mezzanine Cards (FMCs) attached to either of two VITA-57 FPGA mezzanine connectors
provided on the board. High pin count (HPC) and low pin count (LPC) FMCs are provided.
See KC705 Board Features for a complete list of features. The details for each feature are
described in Feature Descriptions, page 9.
Additional Information
See Appendix G, Additional Resources and Legal Notices for references to documents, files,
and resources relevant to the KC705 board.
KC705 Board Features
• Kintex-7 XC7K325T-2FFG900C FPGA
• 1 GB DDR3 memory SODIMM
• 128 MB Linear Byte Peripheral Interface (BPI) flash memory
• 128 Mb Quad Serial Peripheral Interface (SPI) flash memory
• Secure Digital (SD) connector
• USB JTAG via Digilent module
•Clock generation
°
Fixed 200 MHz LVDS oscillator (differential)
°
Inter-integrated circuit (I2C) programmable LVDS oscillator (differential)
°
SMA connectors (differential)
°
SMA connectors for GTX transceiver clocking
