Yamaha YZF-R7 User Manual

3 - 39
CHK
ADJ
CHECKING THE BRAKE HOSES/
BLEEDING THE HYDRAULIC BRAKE SYSTEM
EB304062
CHECKING THE BRAKE HOSES
The following procedure applies to all of
the brake hoses and brake hose clamps.
1. Check:
• brake hose 1
Cracks/damage/wear → Replace.
2. Check:
• brake hose clamp
Loose → Tighten the clamp bolt.
3. Hold the motorcycle upright and apply
the brake several times.
4. Check:
• brake hose
Brake fluid leakage → Replace the
damaged hose.
Refer to “FRONT AND REAR BRAKES”
in chapter 7.
EB304072
BLEEDING THE HYDRAULIC BRAKE
SYSTEM
WARNING
WARNING
Bleed the hydraulic brake system when-
ever:
• the brake system was disassembled,
• a brake hose was loosened, discon-
nected or replaced,
• the brake fluid level is very low,
• brake operation is faulty.
NOTE:
• Be careful not to spill any brake fluid or
allow the brake fluid reservoir to over-
flow.
• When bleeding the hydraulic brake
system, make sure that there is always
enough brake fluid before applying the
brake. Ignoring this precaution could
allow air to enter the hydraulic brake
system, considerably lengthening the
bleeding procedure.
• If bleeding is difficult, it may be neces-
sary to let the brake fluid settle for a
few hours. Repeat the bleeding proce-
dure when the tiny bubbles in the hose
have disappeared.

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
