Yamaha YZF-R7 User Manual

8 - 1
–+
ELEC
ELECTRICAL COMPONENTS
EB800000
ELECTRICAL
ELECTRICAL COMPONENTS
1 Wire harness
2 Main switch
3 Front brake light switch
4 Ignition coils
5 Clutch switch
6 Throttle position sensor
7 Intake air temperature sensor
8 Intake air pressure sensor
9 Atmospheric pressure sensor
0 Turn signal relay
A Relay unit
B ECU
C CDI unit
D Fuse box
E Fall detection switch
F Starter relay
G Main fuse
H Main relay
I Battery
J Rectifier/regulator
K Rear brake light switch
L Neutral switch
M Speed sensor
N Sidestand switch
O Stator coil assembly
P Oil level switch
Q Pickup coil
R Radiator fan
S Horn
T Coolant temperature
sender
U Thermo switch
V Camshaft sensor
8

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
