Yamaha YZF-R7 User Manual

7 - 55
CHAS
EB703001
FRONT FORK
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
11 Nm (1.1 m
•
kg, 8.0 ft
•
Ib)
T
R
.
.
13 Nm (1.3 m
•
kg, 9.4 ft
•
Ib)
T
R
.
.
26 Nm (2.6 m
•
kg, 19 ft
•
Ib)
T
R
.
.
25 Nm (2.5 m
•
kg, 18 ft
•
Ib)
1
2
3
5
4
6
Order Job/Part Q’ty Remarks
Removing the front fork legs Remove the parts in the order listed.
The following procedure applies to
both of the front fork legs.
Bottom cowling and front cowling Refer to “COWLINGS” in chapter 3.
Front wheel Refer to “FRONT WHEEL AND BRAKE
DISCS”.
1 Front fender 1
2 Upper bracket pinch bolt 1 Loosen.
3 Cap bolt 1 Loosen.
4 Handlebar pinch bolt 2
5 Lower bracket pinch bolt 3
6 Front fork leg 1
For installation, reverse the removal
procedure.
FRONT FORK

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
