Yamaha YZF-R7 User Manual

ENG
4 - 48
SHIFT SHAFT
EB408000
SHIFT SHAFT
Order Job/Part Q’ty Remarks
Removing the shift shaft and stop-
per lever
Remove the parts in the order listed.
Drive sprocket cover Refer to “ENGINE”.
1 Shift shaft cover 1
2 Shift shaft cover gasket 1
3 Dowel pin 2
4 Shift shaft 1
5 Shift shaft spring 1
6 Spacer 1
7 Stopper lever spring 1
8 Stopper lever 1
9 Circlip 1
10 Collar 1
11 Shift shaft spring stopper 1
For installation, reverse the removal
procedure.

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
