2 - 21
SPEC
CHASSIS TIGHTENING TORQUES
HINWEIS:
NOTE:
1.First, tighten the ring nut to approximately 18 Nm (1.8 m • kg, 13 ft • lb) with a torque
wrench, then loosen the ring nut completely.
2.Retighten the ring nut to specification.
Item Thread size
Tightening torque
Remarks
Nm m·kgf ft·lb
Upper bracket pinch bolts M8 26 2.6 19
Steering stem nut M28 115 11.5 85
Handlebar pinch bolts M6 13 1.3 9.4
Lower ring nut M30 9 0.9 6.5 See NOTE.
Lower bracket pinch bolts M6 11 1.1 8.0
Front brake hose union bolts M10 30 3.0 22
Front brake master cylinder M6 13 1.3 9.4
Engine mounting
Spacer bolts M16 18 1.8 13
Left front mounting bolts M10 40 4.0 29
Right front mounting bolts M10 40 4.0 29
Rear mounting bolts M10 55 5.5 40
Pinch bolts M8 17 1.7 12
Exhaust pipe bracket M8 24 2.4 17
Pivot shaft nut M18 125 12.5 90
Connecting arms M10 40 4.0 29
Relay arm and connecting arms M10 40 4.0 29
Relay arm M10 40 4.0 29
Rear shock absorber and relay arm M10 40 4.0 29
Rear shock absorber assembly M10 40 4.0 29
Fuel pump and fuel tank M5 4 0.4 2.9
Coolant reservoir and radiator M6 5 0.5 3.6
Rider footrest bracket M8 28 2.8 20
Rear master cylinder M8 23 2.3 17
Rear brake hose union bolts M10 30 3.0 22
Sidestand bracket M8 26 2.6 19
Front wheel axle M20 79 7.9 57
Rear wheel axle M24 150 15.0 110
Rear wheel axle nut M24 45 4.5 32
Front brake caliper and front fork M10 40 4.0 29
Rear brake caliper and bracket M10 40 4.0 29
Brake disc and wheel M6 18 1.8 13
Rear wheel sprocket and rear wheel
drive hub
M10 69 6.9 50
Brake caliper and bleed screw M8 6 0.6 4.3
Pinch bolt (front wheel axle) M8 23 2.3 17
TIGHTENING TORQUES
