Yamaha YZF-R7 User Manual

3 - 20
CHK
ADJ
CHECKING THE SPARK PLUGS/
MEASURING THE COMPRESSION PRESSURE
5. Check:
• electrodes 1
Damage/wear → Replace the spark
plug.
• insulator 2
Abnormal color → Replace the spark
plug.
Normal color is medium-to-light tan.
6. Clean:
• spark plug
(with a spark plug cleaner or wire
brush)
7. Measure:
• spark plug gap a
(with a wire gauge)
Out of specification → Regap.
8. Install:
• spark plug
NOTE:
Before installing the spark plug, clean
the spark plug and gasket surface.
Spark plug gap
0.7 ~ 0.8 mm (0.028 ~ 0.031 in)
T
R
.
.
13 Nm (1.3 m · kg, 9.4 ft · lb)
EB303060
MEASURING THE COMPRESSION
PRESSURE
The following procedure applies to all of
the cylinders.
NOTE:
Insufficient compression pressure will
result in a loss of performance.
1. Measure:
• valve clearance
Out of specification → Adjust.
Refer to “ADJUSTING THE VALVE
CLEARANCE”.
2. Start the engine, warm it up for several
minutes, and then stop it.

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
