Yamaha YZF-R7 User Manual

7 - 25
CHAS
EB702305
Order Job/Part Q’ty Remarks
Disassembling the rear brake caliper Remove the parts in the order listed.
1 Brake pad clip 4
2 Brake pad pin 2
3 Brake pad spring 1
4 Brake pad 2
5 Brake caliper piston 2
6 Brake caliper piston seal 4
7 Bleed screw 2
For assembly, reverse the disassembly
procedure.
FRONT AND REAR BRAKES

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
