3 - 7
CHK
ADJ
Order Job/Part Q’ty Remarks
Removing the rear cowling
Remove the parts in the order listed.
1 Rear fender 1
2 Rear fender panel 1
3 Tail/brake light connector 2 Disconnect.
4 Rear turn signal connector 4 Disconnect.
5 Rear cowling 1
For installation, reverse the removal
procedure.
COWLINGS
To Next Page
