Yamaha YZF-R7 User Manual

8 - 17
–+
ELEC
CHARGING SYSTEM
TROUBLESHOOTING
C0NTINUITYOK
C0NTINUITYOK
No good
C0NTINUITYOK
C0NTINUITYOK
NOTE:
• Before troubleshooting, remove the following part(-s):
1)bottom cowling
2)front cowling
3)rear cowling
• Troubleshoot with the following special tool(-s).
The battery is not being charged.
Check the main fuse for continu-
ity.
Replace.
Check the condition of the bat-
tery.
Recharge or replace.
Measure the charging voltage. The charging circuit is OK.
Measure the stator coil assembly
resistance.
Replace.
Check the entire charging sys-
tem’s wiring.
Repair or replace.
Replace the rectifier/regulator.
Engine tachometer
90890-06760
Pocket tester
90890-03112
No good
No good
No good
No good
ON

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
