7 - 86
CHAS
EB707700
INSTALLING THE SWINGARM
1. Lubricate:
• bearings
• spacers
• dust covers
• pivot shaft
2. Install:
• spacers
• swingarm
• pivot shaft bosses
• pivot shaft
• washer
• pivot shaft nut
3. Install:
• drive chain pullers
NOTE:
Install the drive chain pullers onto the
swingarm so that the sides stamped
“IN” face toward the inside (i.e., the rear
wheel).
4. Install:
• rear shock absorber assembly
• rear wheel
Refer to “REAR SHOCK ABSORBER
ASSEMBLY” and “REAR WHEEL”.
5. Adjust:
• drive chain slack
Refer to “ADJUSTING THE DRIVE
CHAIN SLACK” in chapter 3.
Recommended lubricant
Molybdenum disulfide grease
Drive chain slack
40 ~ 50 mm (1.57 ~ 1.97 in)
T
R
.
.
125 Nm (12.5 m · kg, 90 ft · lb)
SWINGARM AND DRIVE CHAIN
