5 - 5
COOL
1
3

2
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
RADIATOR AND THERMOSTAT
EB502010
Order Job/Part Q’ty Remarks
Disassembling the thermostat
assembly
Remove the parts in the order listed.
1 Thermostat housing cover 1
2 Thermostat 1
3 Thermostat housing 1
For assembly, reverse the disassembly
procedure.

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
