Yamaha YZF-R7 User Manual

8 - 8
–+
ELEC
IGNITION SYSTEM
TROUBLESHOOTING
C0NTINUITYOK
C0NTINUITYOK
C0NTINUITYOK
No good
C0NTINUITYOK
C0NTINUITYOK
C0NTINUITYOK
C0NTINUITYOK
C0NTINUITYOK
C0NTINUITYOK
C0NTINUITYOK
C0NTINUITYOK
C0NTINUITYOK
The ignition system fails to operate (no spark or intermittent spark).
Check the main and ECU fuses for
continuity.
Replace.
Check the condition of the bat-
tery.
Recharge or replace.
Check the spark plug. Re-gap or replace.
Measure the ignition spark gap. Ignition system is OK.
Measure the ignition coil resis-
tance.
Replace.
Measure the pickup coil resis-
tance.
Replace.
Check the main switch. Replace.
Check the engine stop switch.
Replace the right handlebar
switch.
Check the neutral switch. Replace.
Check the diode. Replace.
Check the sidestand switch. Replace.
Check the relay unit. Replace.
Check the entire ignition sys-
tem’s wiring.
Repair or replace.
Replace the CDI unit.
No good
No good
No good
No good
No good
No good
No good
No good
No good
OK
No good
No good
No good

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
