Yamaha YZF-R7 User Manual

6 - 3
EFI
T
R
.
.
30 Nm (3.0 m
•
kg, 22 ft
•
Ib)
T
R
.
.
8 Nm (0.8 m
•
kg, 5.8 ft
•
Ib)
T
R
.
.
5 Nm (0.5 m
•
kg, 3.6 ft
•
Ib)
T
R
.
.
8 Nm (0.8 m
•
kg, 5.8 ft
•
Ib)
(4)
1
2
3
4
5
6
7
10
9
8
11
20
12
14
11
12
13
15
19
16
18
17
LT
LT
LT
LT
LT
LT
ELECTRONIC FUEL INJECTION
Order Job/Part Q’ty Remarks
Removing the injector 2 Remove the parts in the order listed.
1 Intake air pressure sensor coupler 1
2 Atmospheric pressure sensor cou-
pler
1
3 Cylinder #1 – injector 2 coupler 1
4 Cylinder #2 – injector 2 coupler 1
5 Cylinder #3 – injector 2 coupler 1
6 Cylinder #4 – injector 2 coupler 1
7 Pressure sensor hose 2
8 Intake air pressure sensor 1
9 Atmospheric pressure sensor 1
10 Pressure sensor bracket 1
11 Union bolt 2
12 Washer 4

Yamaha YZF-R7 Specifications

General

Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel injection
Final Drive	Chain
Front Brakes	Dual 298mm hydraulic disc; ABS
Rear Brakes	245mm hydraulic disc; ABS
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
Wheelbase	54.9 in
Seat Height	32.9 in
Fuel Capacity	3.4 gal
Wet Weight	414 lb
Ground Clearance	5.3 in
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valves
Transmission	6-speed
Front Suspension	41mm KYB inverted fork, adjustable preload, rebound and compression damping; 5.1-in travel
Rear Suspension	Single shock, adjustable preload and rebound damping; 5.1-in travel
